Tool Bar
When selected for display, the toolbar appears under the Main Menu. The icons and purposes of the buttons are as follows:
Elements referenced in the Selected Clashes are added to the Drawlist.
Sets Owner Discipline of selected records to Discipline of First element.
Sets Owner Discipline of selected records to Discipline of Second element.
Sets status of selected records to Approved.
Sets status of selected records to Unapproved.
Sets status of selected records to Pending.
Sets status of selected records to Conditional.
Clears the graphics display.
Clears the Clash Group/index Text Labels on the graphics display.
If Clash Groups are displayed, refreshes the groups with the current filter and clears the Clash Detail report.
If Clash Detail report alone is displayed, refreshes the Clash Detail using the current filter.
Finds selected data on the current report.
Applies the filter criteria to the data displayed.
Leads to the Clash Manager -
Filter Form
.
Displays the filter pane.
Note:
Some of the icons above will not be available if the User has insufficient access rights, as set by the Administrator.
